Mastering Audio

For the first time in a NewTek UHD camera, Professional XLR audio input seamlessly runs with equipment such as microphones, mixers, amplifiers, and soundboards.

Mastering Video

The PTZ3 UHD takes pan/tilt/zoom quality to new levels; ease-in and ease-out movements deliver seamless, smooth transitions for a natural, superior quality production without jittery or stuttering movements.

Mastering Connectivity

Whether it's using a single cable for audio and video, PTZ control, tally and PoE for power or connecting via NDI^®, NewTek PTZ Cameras simply appear on the network and can immediately be built into any workflow with ease.

Exceptional video for any workflow.

Constructed with NDI^® at its core, the PTZ3 UHD guarantees the tightest integration with any NewTek live production system and any NDI^® workflow – offering professional audio, pristine 4Kp60 and infinite production possibilities.

Phenomenal PTZ At Your Fingertips

Bringing you the very best that PTZ cameras have to offer – all built with NDI at its core.

Vibrant Video
The only NewTek camera that offers 4Kp60 ultra-high-definition video and a state-of-the-art Sony sensor, it’s the very best way to deliver video into any IP environment.

Advanced Audio
The PTZ3 UHD has brought the need for superior audio right into focus with the Professional XLR audio input. Audio devices such as microphones and sound mixers are now easily connected.

Masterful Movement
The PTZ3 UHD offers far superior visual quality with ease-in and ease-out movements between camera presets offering natural, superior quality production, in any environment.

Connectivity At Its Core

Built to ensure that its the best and easiest way of getting the highest quality video and audio onto any network and into any production.

Video Output	NDI|HX, 3G-SDI, HDMI
Video Formats	2160p: 60, 59.94, 50, 30, 29.97, 25 1080p: 60, 59.94, 50, 30, 29.97, 25, 24 720p: 60, 59.94, 50, 30, 29.97, 25
Lens	30 x Optical & 2x digital zoom
Sensor	Sony 1/1.8 inch 12MP sensor.
Shutter Speed	1/30 to 1/10,000 sec
Panning Angle	-170° to +170°
Tilting Angle	-30° to +90°
Audio Input	Mini XLR, 3.5mm stereo audio input (line)
Horizontal Viewing Angle	60°(Far)-2°(Near)
Focal Length	6.91mm~214.64mm
Aperture	F1.8 ~ F14
Min. Object Distance	(Tele) 1.5M
Min. Illumination	0.1 lux
Tally	Supported
User Interface	Web based or NewTek NDI® Studio Monitor applications for remote configuration, control,and monitoring
Networking	1 Gigabit Ethernet
Control	NDI
Power	POE+ (IEEE 802.3 at) or DC12V Power Supply
