Connect Pro
Product Highlights
  • PC Software for IP Video Hosting
  • 4 Simultaneous Video Signals
  • Local or IP Video Sources
  • NDI, ASPEN, and SMPTE 2022 Compatible
  • Built-In Color Correction
  • Up to 8 Audio Channels

  • Overview

Connect hardware, software, and IP sources of any format.

Transform your workflow, adding channels and emerging technologies with the only universal IP video translation solution—NewTek Connect Pro. A four-channel software application supporting any combination of formats and standards to include NDI®, ASPEN, and SMPTE 2022, NewTek Connect Pro allows you to use a standard PC to serve video across your network to and from hundreds of compatible systems and devices for switching, streaming, display, and distribution.

Get connected with NewTek Connect Pro:
  • Up to 4 channels, each configurable as input or output, for any combination of supported sources with built-in standards conversion
  • Supports interoperability between common IP standards to include NDI, ASPEN, and SMPTE 2022*
  • Support for common IP cameras to include models from JVC, Panasonic, PTZ Optics, Sony, and Vaddio
  • Support for capture devices from manufacturers that include AJA, Blackmagic Design, BlueFish 444, DELTACAST, Magewell, Matrox, Teradek, and others, including key and fill pairing on input and output for appropriate video cards; DirectShow devices, webcams, USB3 capture devices, and more*
  • Support for a range of video over IP sources, including RTMP, RTSP, and HTTP streams
  • Support for input of compatible devices and software via Apple AirPlay
  • Support for common audio capture and output devices including professional audio cards, AES67, and Dante*
  • 4 channels of integrated media playback, with support for all common media files and still images (including alpha channel), and Autoplay on NDI tally
  • High-quality still image grab from any source, with motion-adaptive deinterlacing
  • NDI Connect Webserver for remote viewing of NDI sources from a web browser of any networked device, including iOS and Android devices
  • 8-channel audio, with per-channel level control and headphone monitoring
  • Fully configurable color correction settings, including white balance, proc amp controls, and automatic color correction
  • Integrated Waveform and Vectorscope for real-time signal monitoring and adjustment
  • Full field-rate, deinterlaced multi-view monitoring with supplemental NDI program return monitor
  • Configurable workspaces, including support for dual displays and optional graticule overlays, including VU meters, title safe, 4:3 safe, alpha channel checkerboard, and center cross
  • Frame-rate and resolution cross conversion, frame sync and audio reclocking on all inputs, with adjustable per-channel A/V sync

Minimum System Requirements
  • Operating System: Microsoft Windows 7 (64-bit)
  • CPU: Intel Core i5 Sandy Bridge
  • GPU: Intel integrated GPU (NVIDIA GPU with 2GB of vRAM or more recommended)
  • Memory: 8 GB
  • Ethernet: Gigabit
  • Screen Resolution: 1024 x 768
