Designed for use anywhere that you might need it, the DNS 2 offers
- The latest adaptive noise suppression techmology
- The fastest and most intiutive interface ever designed for DNS
- Analogue and digital inputs and outputs
- 12V operation and camera mounting points
- Overview
- Tech Specs
The smallest, lightest and most convenient dialogue noise suppressor for location and studio use
The DNS 2 offers virtually zero latency so it can be used live without loss of lip-sync. Yet it still eliminates traffic noise, air conditioning, wind, rain, babble and general background noise, compensates for unfavourable acoustics and poor microphone placement, and suppresses excessive reverberation.
It can even output simultaneously the raw and processed versions of a single signal, which makes it ideal for use on location as well as in the studio and in all live situations; not just live-to-air broadcasting, but also for live sound in venues such as theatres, concert halls, conferences venues, and places of worship.
| Number of channels | 2 |
| Process type | CEDAR DNS with Learn |
| Analogue audio | |
| Mic and line inputs | Balanced XLR3F |
| Line output | Balanced XLR3M |
| Output signal level | +4dBu nominal |
| Maximum output | +24dBu |
| AD/DA resolution | 24-bit linear PCM |
| Sample rate (internal sync) | 48kHz |
| Sample rate (external sync) | 40kHz - 100kHz |
| Phantom power on mic inpu | 48V ±4V, 10mA per mic |
| Digital audio | |
| Input | AES3 or AES11 via balanced XLR3F |
| Sample rate sync range | 40kHz - 100kHz |
| Output | AES3 via balanced XLR3M |
| Sample rate (internal sync) | 48kHz |
| Sample rate (external sync) | Locked to input |
| Processing | |
| Process resolutio | 40-bit, floating-point |
| Latency | <0.1ms |
| Power | |
| Input | 8-17.5VDC on XLR4M |
| Supplied adapter | |
| Input | 85-250VAC, 50-60Hz |
| Output | 12V, 1A (max) |
| Dimensions | |
| Size | 146mm x 110mm x 44mm |
| Weight | 540g |
