Dynaudio Core 47
Dynaudio

Core 47

3-way Powered Studio Monitor
Key features
  • Loaded with proprietary 1" Esotar Pro tweeter coupled with 4" mid- and 7" low-frequency MSP (Magnesium Silicate Polymer) drivers
  • Class D Pascal tri-amplification HF 150W/MF 500W/LF 500W for massive headroom
  • Front-loaded bass reflex cabinet for tight, focused lows and solid imaging
  • Analog and AES3 digital inputs let you keep your signal digital right to the end
  • 24-bit sampling rate and 192kHz resolution; dependent on input signal
  • Core DSP optimizes imaging, balance, and bass extension
  • All drivers handcrafted by Dynaudio in Denmark
  • Overview
  • Tech Specs

For most professional studio engineers, the very idea of a compact, 7" 3-way studio monitor sounds nearly impossible. Leave it to Dynaudio to show us how it's done. With extraordinary clarity, tons of headroom, and unbelievable definition across the frequency spectrum, engineers here at Sweetwater have found Core 47 studio monitors show exactly what you can pack in a reasonably small studio monitor.

Highlights of the Dynaudio Core 47 include a 3-way design, with a 7" low-frequency and a 4" midrange MSP (Magnesium Silicate Polymer) driver, and a 1" Esotar Pro tweeter. These speakers are tri-amped for a total of 1,150 watts (500W + 500W + 150W) of amplification — a recipe for extreme headroom. Between its cutting edge waveguide and front-facing bass reflux design, you'll get the kind of focused full-range sound you'd expect from a 2.1 stereo setup, and a wide sweet spot that doesn't sacrifice an iota of stereo imaging. And between extremely flexible mounting options and stellar onboard digital conversion, Dynaudio Core 47 studio monitors are among the finest we've heard.

Tweeter 1in
Midrange 4in
Woofer 7in
Inputs Analogue and AES3 digital inputs (no sample-rate conversion)
Resolution Maximum 24-bit / 192 kHz, depending on input signal
32, 44.1, 48, 96 & 192 kHz sample rates supported, analogue runs at 192 kHz
Maximum SPL 112 dB @ 1 m anechoic
118 dB half space
Crossover frequency 475 Hz (LF/MF) / 5250 Hz (MF/HF)
Frequency response (- 6 dB) 37 Hz – 31 kHz
Frequency response (+/- 3 dB) 44 Hz – 27 kHz
Box principle Front-loaded bass reflex
Amplifiers Pascal Class-D amplifiers: HF 150 W / MF 500 W / LF 500 W

Dimensions & Weight
  • Dimensions (WxDxH):
    390 mm, 355 mm, 240 mm (W x D x H)
    15 3⁄8in, 14in, 9 7/16in (W x D x H)
  • Weight:
    15.1 kg (33.3 lb)
